J. Semicond. > Volume 37 > Issue 5 > Article Number: 054002

A novel sub 20 nm single gate tunnel field effect transistor with intrinsic channel forultra low power applications

Pranav Kumar Asthana 1, , Yogesh Goswami 1, and Bahniman Ghosh 1, 2,

+ Author Affilications + Find other works by these authors

PDF

Abstract: We propose a nanoscale single gate ultra thin body intrinsic channel tunnel field effect transistor using the charge plasma concept for ultra low power applications. The characteristics of TFETs (having low leakage) are improved by junctionless TFETs through blending advantages of Junctionless FETs (with high on current). We further improved the characteristics, simultaneously simplifying the structure at a very low power rating using an InAs channel. We found that the proposed device structure has reduced short channel effects and parasitics and provides high speed operation even at a very low supply voltage with low leakage. Simulations resulted in IOFF of ~ 9 × 10-16A/μm, ION of ~20 μA/μm, ION/IOFF of ~2 × 1010, threshold voltage of 0.057 V, subthreshold slope of 7 mV/dec and DIBL of 86 mV/V for PolyGate/HfO2/InAs TFET at a temperature of 300 K, gate length of 20 nm, oxide thickness of 2 nm, film thickness of 10 nm, low-k spacer thickness of 10 nm and VDD of 0.2 V.

Key words: band-to-band tunneling (BTBT)tunnel field effect transistor (TFET)junctionless tunnel field effect transistor (JLTFET)ION/IOFF ratiolow power

Abstract: We propose a nanoscale single gate ultra thin body intrinsic channel tunnel field effect transistor using the charge plasma concept for ultra low power applications. The characteristics of TFETs (having low leakage) are improved by junctionless TFETs through blending advantages of Junctionless FETs (with high on current). We further improved the characteristics, simultaneously simplifying the structure at a very low power rating using an InAs channel. We found that the proposed device structure has reduced short channel effects and parasitics and provides high speed operation even at a very low supply voltage with low leakage. Simulations resulted in IOFF of ~ 9 × 10-16A/μm, ION of ~20 μA/μm, ION/IOFF of ~2 × 1010, threshold voltage of 0.057 V, subthreshold slope of 7 mV/dec and DIBL of 86 mV/V for PolyGate/HfO2/InAs TFET at a temperature of 300 K, gate length of 20 nm, oxide thickness of 2 nm, film thickness of 10 nm, low-k spacer thickness of 10 nm and VDD of 0.2 V.

Key words: band-to-band tunneling (BTBT)tunnel field effect transistor (TFET)junctionless tunnel field effect transistor (JLTFET)ION/IOFF ratiolow power
