W-band high output power Schottky diode doublers with quartz substrate

Changfei Yao 1, 2, , , Ming Zhou 2, , Yunsheng Luo 2, , Jiao Li 2, and Conghai Xu 2,

+ Author Affiliations + Find other works by these authors

PDF

Abstract: W-band quartz based high output power fix-tuned doublers are analyzed and designed with planar Schottky diodes. Full-wave analysis is carried out to find diode embedding impedances with a lumped port to model the nonlinear junction. Passive networks of the circuit, such as the low pass filter, the E-plane waveguide to strip transitions, input and output matching networks, and passive diode parts are analyzed by using electromagnetic simulators, and the different parts are then combined and optimized together. The exported S-parameters of the doubler circuit are used for multiply efficiency analysis. The highest measured output power is 29.5 mW at 80 GHz and higher than 15 mW in 76-94 GHz. The highest measured efficiency is 11.5% at 92.5 GHz, and the typical value is 6.0% in 70-100 GHz.

Key words: high output powerfrequency doublerplanar Schottky diodeefficiency

Abstract: W-band quartz based high output power fix-tuned doublers are analyzed and designed with planar Schottky diodes. Full-wave analysis is carried out to find diode embedding impedances with a lumped port to model the nonlinear junction. Passive networks of the circuit, such as the low pass filter, the E-plane waveguide to strip transitions, input and output matching networks, and passive diode parts are analyzed by using electromagnetic simulators, and the different parts are then combined and optimized together. The exported S-parameters of the doubler circuit are used for multiply efficiency analysis. The highest measured output power is 29.5 mW at 80 GHz and higher than 15 mW in 76-94 GHz. The highest measured efficiency is 11.5% at 92.5 GHz, and the typical value is 6.0% in 70-100 GHz.

Key words: high output powerfrequency doublerplanar Schottky diodeefficiency



References:

[1]

Porterfield D W, Crowe T W, Bradley R F. A high-power fixed-turned millimeter-wave balanced frequency doubler[J]. IEEE Trans Microw Theory Tech, 1999, 47(4): 419. doi: 10.1109/22.754875

[2]

Maestrini A, Ward J, Gill J. A 1.7 to 1.9 THz local oscillator source[J]. IEEE Trans Microw Wireless Compon Lett,, 2004, 14(6): 253. doi: 10.1109/LMWC.2004.828027

[3]

Maestrini A, Ward J S, Javadi H. Local oscillator chain for 1.55 to 1.75 THz with 100μ W peak power[J]. IEEE Trans Microw Wireless Compon Lett, 2005, 15(12): 871. doi: 10.1109/LMWC.2005.859989

[4]

Maestrini A, Ward J S, Gill J J. A 540-640-GHz high-efficiency four-anode frequency tripler[J]. IEEE Trans Microw Theory Tech, 2005, 53(9): 2835. doi: 10.1109/TMTT.2005.854174

[5]

Xiao Q, Hesel J L, Crowe T W. A 270 GHz tuner-less heterostructure barrier varactor frequency triplier[J]. IEEE Trans Microw Wireless Compon Lett, 2007, 17(4): 241. doi: 10.1109/LMWC.2007.892932

[6]

Maestrini A, Ward J S, Chattopadhyay G. THz sources based on frequency multiplication and their applications[J]. J RF-Eng Telecommun, 2008, 5(6): 118.

[7]

Maestrini A, Ward J S, Charlotte T C. In-phase power-combined frequency triplers at 300 GHz[J]. IEEE Trans Microw Wireless Compon Lett, 2008, 18(3): 218. doi: 10.1109/LMWC.2008.916820

[8]

Bryllert T, Malko A, Vukusic J. A 175 GHz HBV frequency quintupler with 60 mW output power[J]. IEEE Trans Microw Wireless Compon Lett, 2012, 22(2): 76. doi: 10.1109/LMWC.2011.2181494

[9]

Chattopadhyay G. Technology, capabilities, and performance of low power terahertz sources[J]. IEEE Trans Microw Theory Tech, 2011, 1(1): 33.

[10]

Papapolymerou J, East J, Katehi L P B. A high-power W-band monolithic FGC doubler[J]. IEEE Trans Microw Wireless Compon Lett, 2000, 10(5): 195.

[11]

[OL]: http://www.radiometer-physics.de/.

[12]

[OL]: http://www.vadiodes.com/.

[13]

Bryllert T, Vukusic J, Emadi T A. A high-power frequency tripler for 100 GHz[J]. Infrared Millimeter Waves and 14th International Conference on Teraherz Electronics, 2006: 18.

[14]

Yao C F, Zhou M, Luo Y S. Millimeter wave fixed-tuned subharmonic mixers with planar Schottky diodes[J]. Journal of Semiconductors, 2012, 33(11): 115007. doi: 10.1088/1674-4926/33/11/115007
