A novel SOI pressure sensor for high temperature application

Sainan Li 1, 2, , Ting Liang 1, 2, , , Wei Wang 1, 2, , Yingping Hong 1, 2, , Tingli Zheng 1, 2, and Jijun Xiong 1, 2,

+ Author Affilications + Find other works by these authors

PDF

Abstract: The silicon on insulator (SOI) high temperature pressure sensor is a novel pressure sensor with high-performance and high-quality. A structure of a SOI high-temperature pressure sensor is presented in this paper. The key factors including doping concentration and power are analyzed. The process of the sensor is designed with the critical process parameters set appropriately. The test result at room temperature and high temperature shows that nonlinear error below is 0.1%, and hysteresis is less than 0.5%. High temperature measuring results show that the sensor can be used for from room temperature to 350 ℃ in harsh environments. It offers a reference for the development of high temperature piezoresistive pressure sensors.

Key words: SOIhigh temperature pressure sensordoping concentrationpower

Abstract: The silicon on insulator (SOI) high temperature pressure sensor is a novel pressure sensor with high-performance and high-quality. A structure of a SOI high-temperature pressure sensor is presented in this paper. The key factors including doping concentration and power are analyzed. The process of the sensor is designed with the critical process parameters set appropriately. The test result at room temperature and high temperature shows that nonlinear error below is 0.1%, and hysteresis is less than 0.5%. High temperature measuring results show that the sensor can be used for from room temperature to 350 ℃ in harsh environments. It offers a reference for the development of high temperature piezoresistive pressure sensors.

Key words: SOIhigh temperature pressure sensordoping concentrationpower
