Waveguide-integrated optical modulators with two-dimensional materials

Haitao Chen; Hongyuan Cao; Zejie Yu; Weike Zhao; Daoxin Dai

doi:10.1088/1674-4926/44/11/111301

J. Semicond. > 2023, Volume 44 > Issue 11 > 111301

REVIEWS

Waveguide-integrated optical modulators with two-dimensional materials

Haitao Chen^{1, 2, 3}, Hongyuan Cao¹, Zejie Yu¹, Weike Zhao¹ and Daoxin Dai^{1, 4,}

+ Author Affiliations

1. State Key Laboratory for Modern Optical Instrumentation, College of Optical Science and Engineering, International Research Center for Advanced Photonics, Zhejiang University, Zijingang Campus, Hangzhou 310058, China
2. College of Advanced Interdisciplinary Studies & Hunan Provincial Key Laboratory of Novel Nano-Optoelectronic Information Materials and Devices, National University of Defense Technology, Changsha 410073, China
3. Nanhu Laser Laboratory, National University of Defense Technology, Changsha 410073, China
4. Ningbo Research Institute, Zhejiang University, Ningbo 315100, China

Author Bio:

Haitao Chen received his BS from the National University of Defense Technology (NUDT, China) in 2012 and PhD from Nonlinear Physics Center, the Australian National University (ANU, Australia) in 2018. He then joined the National University of Defense Technology as a lecturer. He worked at Daoxin Dai Group in Zhejiang University (ZJU, China) as a visiting postdoctral fellow during the years 2020−2022. His research interests include silicon integrated nanophotonics, nonlinear photonics, and 2D materials photonics.

Daoxin Dai received his BS from Zhejiang University (ZIU, China) in 2000 and PhD from the Royal Institute of Technology (KTH, Sweden) in 2005. Later, he joined ZJU as an assistant professor in Aug. 2007 and a full professor in 2011. He worked at Bowers Group in the University of California at Santa Barbara (UCSB) as a visiting scholar during the years 2008−2011. Currently, he is the Qiushi Distinguished Professor and leading the silicon integrated nanophotonics group at Zhejiang University. He serves as the Dean of Optical Science & Engineering of Zhejiang University and the Director of MOE Joint International Research Laboratory of Photonics @ ZJU.

Corresponding author: Daoxin Dai, dxdai@zju.edu.cn

DOI: 10.1088/1674-4926/44/11/111301

Abstract: Waveguide-integrated optical modulators are indispensable for on-chip optical interconnects and optical computing. To cope with the ever-increasing amount of data being generated and consumed, ultrafast waveguide-integrated optical modulators with low energy consumption are highly demanded. In recent years, two-dimensional (2D) materials have attracted a lot of attention and have provided tremendous opportunities for the development of high-performance waveguide-integrated optical modulators because of their extraordinary optoelectronic properties and versatile compatibility. This paper reviews the state-of-the-art waveguide-integrated optical modulators with 2D materials, providing researchers with the developing trends in the field and allowing them to identify existing challenges and promising potential solutions. First, the concept and fundamental mechanisms of optical modulation with 2D materials are summarized. Second, a review of waveguide-integrated optical modulators employing electro-optic, all-optic, and thermo-optic effects is provided. Finally, the challenges and perspectives of waveguide-integrated modulators with 2D materials are discussed.

Key words: optical modulation, two-dimensional (2D) materials, on-chip, waveguide
