Lower-power, high-linearity class-AB current-mode programmable gain amplifier

Yiqiang Wu , Zhigong Wang , , Junliang Wang , Li Ma , Jian Xu and Lu Tang

+ Author Affilications + Find other works by these authors

PDF

Abstract: A novel class-AB implementation of a current-mode programmable gain amplifier (CPGA) including a current-mode DC offset cancellation loop is presented. The proposed CPGA is based on a current amplifier and provides a current gain in a range of 40 dB with a 1 dB step. The CPGA is characterized by a wide range of current gain variation, a lower power dissipation, and a small chip size. The proposed circuit is fabricated using a 0.18 μm CMOS technology. The CPGA draws a current of less than 2.52 mA from a 1.8 V supply while occupying an active area of 0.099 μm2. The measured results show an overall gain variation from 10 to 50 dB with a gain error of less than 0.40 dB. The OP1dB varies from 11.80 to 13.71 dBm, and the 3 dB bandwidth varies from 22.2 to 34.7 MHz over the whole gain range.

Key words: current modeclass ABprogrammable gain amplifiercurrent amplifier

Abstract: A novel class-AB implementation of a current-mode programmable gain amplifier (CPGA) including a current-mode DC offset cancellation loop is presented. The proposed CPGA is based on a current amplifier and provides a current gain in a range of 40 dB with a 1 dB step. The CPGA is characterized by a wide range of current gain variation, a lower power dissipation, and a small chip size. The proposed circuit is fabricated using a 0.18 μm CMOS technology. The CPGA draws a current of less than 2.52 mA from a 1.8 V supply while occupying an active area of 0.099 μm2. The measured results show an overall gain variation from 10 to 50 dB with a gain error of less than 0.40 dB. The OP1dB varies from 11.80 to 13.71 dBm, and the 3 dB bandwidth varies from 22.2 to 34.7 MHz over the whole gain range.

Key words: current modeclass ABprogrammable gain amplifiercurrent amplifier
