J. Semicond. > Volume 40 > Issue 5 > Article Number: 052301

Multi-channel 28-GHz millimeter-wave signal generation on a silicon photonic chip with automated polarization control

Ruiyuan Cao , Yu He , Qingming Zhu , Jingchi Li , Shaohua An , Yong Zhang and Yikai Su ,

+ Author Affilications + Find other works by these authors

PDF

Turn off MathJax

Abstract: We propose and experimentally demonstrate an integrated silicon photonic scheme to generate multi-channel millimeter-wave (MMW) signals for 5G multi-user applications. The fabricated silicon photonic chip has a footprint of 1.1 × 2.1 mm2 and integrates 7 independent channels each having on-chip polarization control and heterodyne mixing functions. 7 channels of 4-Gb/s QPSK baseband signals are delivered via a 2-km multi-core fiber (MCF) and coupled into the chip with a local oscillator (LO) light. The polarization state of each signal light is automatically adjusted and aligned with that of the LO light, and then 7 channels of 28-GHz MMW carrying 4-Gb/s QPSK signals are generated by optical heterodyne beating. Automated polarization-control function of each channel is also demonstrated with ~7-ms tuning time and ~27-dB extinction ratio.

Key words: multi-channelmillimeter-wave (MMW) generationsilicon photonic integrated circuitssilicon polarization control (SPC)

Abstract: We propose and experimentally demonstrate an integrated silicon photonic scheme to generate multi-channel millimeter-wave (MMW) signals for 5G multi-user applications. The fabricated silicon photonic chip has a footprint of 1.1 × 2.1 mm2 and integrates 7 independent channels each having on-chip polarization control and heterodyne mixing functions. 7 channels of 4-Gb/s QPSK baseband signals are delivered via a 2-km multi-core fiber (MCF) and coupled into the chip with a local oscillator (LO) light. The polarization state of each signal light is automatically adjusted and aligned with that of the LO light, and then 7 channels of 28-GHz MMW carrying 4-Gb/s QPSK signals are generated by optical heterodyne beating. Automated polarization-control function of each channel is also demonstrated with ~7-ms tuning time and ~27-dB extinction ratio.

Key words: multi-channelmillimeter-wave (MMW) generationsilicon photonic integrated circuitssilicon polarization control (SPC)
