Table 1. Performance comparison of different types image sensor.
Ref. | [1] | [2] | [3] | [5] | [7] |
Sensor type | CIS + EVS | CIS + EVS | CIS + EVS | THz CIS | X-ray SPAD |
Technology | 40 nm BSI CIS + 65 nm CMOS + 3DMIM + 40 nm CMOS | 90 nm BI CIS + 22 nm CMOS | 90 nm BI CIS + 22 nm CMOS | 180 nm CMOS | 65 nm CMOS |
Resolution (pixel) | 1032 × 928(EVS)/ 4096 × 3680(CIS) | 2.08M(EVS)/ 35.6M(CIS) | 640 × 640 | 128 × 128 | 400 × 200 |
Pixel pitch (μm) | 8.8(EVS)/2.2(CIS) | 4.88(EVS)/1.22(CIS) | 2.97 | 60 | 49.5 |
Frame rate (fps) | 18(CIS) | 59(CIS) | 60(CIS) | 130 | 600 |
Dynamic range (dB) | – | 67.8 | 72.2 | 73 | 117.7 |
Random noise (e-) | 2.2 | 1.57 | 2.6 | – | – |
Maximum event rate (Eps) | 4.6G | 4.56G | 1.41G | – | – |
